齒輪減速電機R67功率：

R67Y0.12KW,R67Y0.18KW,R67Y0.25KW,R67Y0.37KW,R67Y0.55KW,R67Y0.75KW,R67Y1.1KW,R67Y1.5KW,R67Y2.2KW,R67Y3KW,R67Y4KW,R67Y5.5KW,R67Y7.5KW（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。

R67減速機減速比：GR系列減速機

4.29比減速器,4.93比減速器,5.70比減速器,6.27比減速器,7.36比減速器,7.97比減速器,8.7比減速器,10比減速器,11.54比減速器,12.70比減速器,14.91比減速器,15.79比減速器,17.95比減速器,19.89比減速器,23.44比減速器,26.72比減速器,28.13比減速器,28.83比減速器,32.27比減速器,37.50比減速器,39.88比減速器,46.29比減速器,51.56比減速器,56.89比減速器,61.26比減速器,69.75比減速器,74.17比減速器,86.11比減速器,95.91比減速器,105.83比減速器,113.94比減速器,128.97比減速器,137.67比減速器,158.14比減速器,184.07比減速器,199.81比減速器

R67減速機安裝尺寸：輸出軸Φ35+鍵3（可定做），高212*寬213*長280（帶輸出軸）

R67減速機臥式輸出轉數：

7轉減速機,7.6轉減速機,8.9轉減速機,10轉減速機,11轉減速機,12轉減速機,13轉減速機,15轉減速機,16轉減速機,19轉減速機,20轉減速機,23轉減速機,25轉減速機,27轉減速機,30轉減速機,35轉減速機,37轉減速機,43轉減速機,49轉減速機,50轉減速機,52轉減速機,60轉減速機,70轉減速機,78轉減速機,89轉減速機,94轉減速機,110轉減速機,121轉減速機,140轉減速機,161轉減速機,180轉減速機,190轉減速機,223轉減速機,246轉減速機,284轉減速機,326轉減速機。（以上轉數均為四級電機算出的，可用兩級電機，六級電機計算，也可以用變頻電機調速）

R67減速機輸出扭矩：

減速箱270N.m,減速箱290N.m,減速箱310N.m,減速箱330N.m,減速箱370N.m,減速箱380N.m,減速箱400N.m,減速箱470N.m,減速箱500N.m,減速箱520N.m,減速箱540N.m,減速箱550N.m,減速箱560N.m,減速箱570N.m,減速箱580N.m,減速箱590N.m,減速箱600N.m。（以上扭矩均為四級電機得出扭矩，需要比上面更大的扭矩，可把電機功率加大，減速機型號加大,或者兩個減速機組合使用）

R67直連減速機電機型號:

R67DV63S4,R67DV71S4,R67DV80S4,R67DV90S4,R67DV100S4,R67DV112S4,R67DV132S4,R67DT63S4,R67DT71S4,R67DT80S4,R67DT90S4,R67DT100S4,R67DT112S4,R67DT132S4,R67DRS63S4,R67DRS71S4,R67DRS80S4,R67DRS90S4,R67DRS100S4,R67DRS112S4,R67DRS132S4,R67DRE63S4,R67DRE71S4,R67DRE80S4,R67DRE90S4,R67DRE100S4,R67DRE112S4,R67DRE132S4,R67Y63S4,R67Y71S4,R67Y80S4,R67Y90S4,R67Y100S4,R67Y112S4,R67Y132S4,R67DV63M4,R67DV71M4,R67DV80M4,R67DV90M4,R67DV100M4,R67DV112M4,R67DV132M4,R67DT63M4,R67DT71M4,R67DT80M4,R67DT90M4,R67DT100M4,R67DT112M4,R67DT132M4,R67DRS63M4,R67DRS71M4,R67DRS80M4,R67DRS90M4,R67DRS100M4,R67DRS112M4,R67DRS132M4,R67DRE63M4,R67DRE71M4,R67DRE80M4,R67DRE90M4,R67DRE100M4,R67DRE112M4,R67DRE132M4,R67Y63M4,R67Y71M4,R67Y80M4,R67Y90M4,R67Y100M4,R67Y112M4,R67Y132M4,R67DV63L4,R67DV71L4,R67DV80L4,R67DV90L4,R67DV100L4,R67DV112L4,R67DV132L4,R67DT63L4,R67DT71L4,R67DT80L4,R67DT90L4,R67DT100L4,R67DT112L4,R67DT132L4,R67DRS63L4,R67DRS71L4,R67DRS80L4,R67DRS90L4,R67DRS100L4,R67DRS112L4,R67DRS132L4,R67DRE63L4,R67DRE71L4,R67DRE80L4,R67DRE90L4,R67DRE100L4,R67DRE112L4,R67DRE132L4,R67Y63L4,R67Y71L4,R67Y80L4,R67Y90L4,R67Y100L4,R67Y112L4,R67Y132L4,

R67減速機配各種電機的實物圖：

R67減速機生產工廠展示：看廠請聯系微信13826972124，獲取位置，需提前一天預約

推薦類似型號：減速機RF67
